技术 - Article 2024.12.11

Application Guide > Automotive > ADAS(Advanced Driver Assistance System) ECU

随着在ADAS ECU上采用的SoC/GPU半导体IC的高性能化，对（超）高容值、高温产品的要求及应对IC周边安装空间有限的小型化要求持续增加。



可适用于此应用的三星电机X7* 高容值MLCC在高温条件下也可以保证较高的可靠性。

另外三星电机也在持续扩大0603 inch以下小尺寸MLCC的line-up和供应。




MLCC 趋势 : 高容，高温

▷ 小型化

▷ 高可靠性

  → 推荐方案 :  X7* PN系列



Size

(inch/mm)

Rated Voltage

[Vdc]

TCC

Capacitance

Part Number

MP

Status

Sample

Availability

0402/1005

10

X7S

2.2㎌

CL05Y225KP66PN#

NEW

Available

0603/1608

10

X7T

10㎌

 CL10Z106MP96PN#

NEW

Available

0805/2012

10

X7R

10㎌

 CL21B106KPY6PN#

In MP

Available

1206/3216

10

X7R

22㎌

CL31B226KPK6PN#

In MP

Available

1210/3225

10

X7S

47㎌

CL32Y476KPVVPN#

In MP

​Available
