Application Guide > Automotive > ADAS(Advanced Driver Assistance System) ECU

ADAS ECUに適用されるSoC/GPU半導体ICの高性能化に伴い、(超)高容量・高温製品に対する要求とIC周辺の実装空間不足に対応するための小型化要求が増え続けています。



このアプリケーションに適用可能なサムスン電機のX7*高容量MLCCは、高温でも高い信頼性を保証します。また、弊社は1608mmサイズ以下の小型サイズMLCCラインナップを継続的に拡大・供給しています。




MLCC Trend : High Capacitance, High Temperature

▷ Miniaturization

▷ High Reliability

 → Recommendation : X7* PN Series



Size

(mm/inch)

Rated Voltage

[Vdc]

TCC

Capacitance

Part Number

MP

Status

Sample

Availability

1005/0402

10

X7S

2.2㎌

CL05Y225KP66PN#

NEW

Available

1608/0603

10

X7T

10㎌

 CL10Z106MP96PN#

NEW

Available

2012/0805

10

X7R

10㎌

 CL21B106KPY6PN#

In MP

Available

3216/1206

10

X7R

22㎌

CL31B226KPK6PN#

In MP

Available

3225/1210

10

X7S

47㎌

CL32Y476KPVVPN#

In MP

​Available
