2024.12.11

サムスン電機 、車載用MLCC 1608mm X7T 10㎌ 10Vを世界で初めて発売

▷ 1.6×0.8mm(0603 inch)サイズ、X7T(-55～125℃)、定格10Vで静電容量10㎌を実現するCL10Z106MP96PN#製品を世界で初めて開発し、量産を開始しました。サンプル提供も可能です。



▷ ADAS Radar、LiDAR、HPC、IVI通信(Wifi、BT、5G、NAD)モジュールおよびSiPモジュールの高集積、高密度、小型化のトレンドが拡散するにつれ、積層セラミックキャパシタへの小型化の要求も増えています。



▷ 今回の新規製品は既存の2.0×1.25mm(0805 inch) 製品と同じ容量・定格電圧を維持しつつ、 1.6×0.8mm(0603 inch)へとサイズを縮小することで、アプリケーションの小型化・高容量設計、高温(125℃)と電圧安定性の要求を同時に満たしています。



▷ サムスン電機は、独自のセラミックおよび電極材料の微粒子化と超精密積層工法を取り入れて、1.6×0.8mm(0603 inch)サイズ、定格10V、10㎌の領域まで製品カバレッジを拡大しました。







Samsung

Size

(mm/inch)

Capacitance

Rated Voltage

TCC
CL10Z106MP96PN#

1608/0603

10㎌

10V

X7T

(X7T : -55℃~125℃ における容量変化率, +22~-33%)



​

Characteristic Data
