Application Guide > Automotive > LED Lighting System

汽车照明部分，LED灯的应用扩大到小型车上，随着汽车的环保、智能化趋势不断进步发展。随着前照灯的智能化, 尾灯的设计变化等LED channel数量的增加及汽车的耗电量上升, 在高温环境中 (~125℃) MLCC有效容值的重要性也越来越大。



对此，三星电机持续扩大供应适合产品设计的 X7R, 35V以上的高容值MLCC产品系列。



MLCC 趋势 : 高容值

▷ 比X7S更高的有效容值

▷ 高可靠性

 → 推荐方案 :  X7R PN 系列



Size

(inch/mm)

Rated Voltage

[Vdc]

TCC

Capacitance

Part Number

MP

Status

Remarks

1210/3225

35Vdc

X7R

22㎌

CL32B226KLV6PJ#

NEW

Soft term.

1210/3225

35Vdc

X7R

22㎌

CL32B226KLV6PN#

NEW



1206/3216

35Vdc

X7R

10㎌

CL31B106KLK6PJ#

In MP

Soft term.

1206/3216

35Vdc

X7R

10㎌

CL31B106KLK6PN#

In MP



0805/2012

35Vdc

X7R

4.7㎌

CL21B475KLB6PJ#

In MP

Soft term.

0805/2012

35Vdc

X7R

4.7㎌

CL21B475KLB6PN#

In MP



0805/2012

35Vdc

X7R

2.2㎌

CL21B225KLYVPJ#

In MP

Soft term.

0805/2012

35Vdc

X7R

2.2㎌

CL21B225KLYVPN#

In MP



0603/1608

35Vdc

X7R

1.0㎌

CL10B105KL9VPJ#

In MP

Soft term.

0603/1608

35Vdc

X7R

1.0㎌

CL10B105KL9VPN#

In MP
