Chip Resistor

High Power Resistor

Product Search Component Library Buy Now

Resistor with High Power Capability

This product has a higher power capability than general products, with approximately three times the power characteristics.
Samsung Electro-Mechanics uses a proprietary technology to maximize the area of the resistor to achieve higher characteristics
than those of competitors.

High power Resistor
Product Search
New Core Technology
Achievement of The Highest Level of Performance
through the Integration
  • Extension of
    Resistor Length
    Application of Serpentine Cut
    with Laser to Resistor
  • Increased
    Resistor Area
    Three-Fold Increase
    in Resistor Area with Printing
    and Laser Cutting
  • Achievement of
    Uniform Thickness
    of Resistors
    Uniform Resistor Thickness
    with Proprietary Printing
    Method

High Power

High Power Lineup - Type, Size Inch/(mm), Feature, Watt [W], Resistance Tolerance[%], Resistance Range, Operation Temperature Range [℃]
Type Size Inch/(㎜) Feature Watt [W] Resistance
Tolerance [%]		 Resistance
Range		 Operation
Temperature
Range [℃]
RCW0603 0201(0603) 1/10 ±0.5%
±1%
±2%
±5%		 1~10MΩ -55~125℃
RCW1005 0402(1005) 1/5
RCW1608 0603(1608) 1/4 -55~155℃
RCW2012 0805(2012) 1/2
RCW3216 1206(3216) 1

Automotive High Power

Automotive High Power Lineup - Type, Size Inch/(mm), Feature, Watt [W], Resistance Tolerance[%], Resistance Range, Operation Temperature Range [℃]
Type Size Inch/(㎜) Feature Watt [W] Resistance
Tolerance [%]		 Resistance
Range		 Operation
Temperature
Range [℃]
RAW2012 0805(2012) 1/2 ±0.5%
±1%
±2%
±5%		 1~10MΩ -55~155℃

Application

  • Network

  • Server

  • Automotive

  • Miniaturization
    for Space Saving

  • Products that Require High Reliability at the Same Size

  • Wireless Charging
    for Smartphones
